Description
Hannay SF Series Booster Hose Reel
The Hannay SF Series Booster Hose Reel is designed to handle 3/4" I.D. or 1" I.D. booster hose.
Features:
- Inboard motor location high profile
- Standard booster hose reel is steel, painted graphite. Aluminum or stainless steel construction is also available
- Choose chain and sprocket rewind powered by either electric or compressed air motor
- Pinion brake standard
- Standard inlet: 1" 90° ball bearing swivel joint with 1" female NPT threads
- Standard outlet: 1" male NST threads (1.375" x 8 threads per inch)
- Consult factory for other sizes and/or threads
- Standard inlet, outlet riser, and hub assembly are steel (also available in stainless steel)
- Rollers and roller mounting brackets are accessory items. Specify roller position.
- Pressures to 1000 psi (69 bar)
- Temperatures from -25°F to +250°F (-32°C to +121°C)
- Consult factory for other pressures and temperatures
- CAUTION: When using Niedner Reeltex hose, a special riser and/or larger drum diameter is required
Details
SKU: |
HY-SF |
